SMN-303A

Self-ejecting NanoSIM card socket with card detection, 6P/7P, with post/without post
SMN-303A

SMN-303A

REACH RoHS ELV
Card installation method Self-eject type
Card insertion detection With detection PIN
Product Type NANO SIM

Basic Parameters

Snap Gauge NANO SIM
Height Above Board 1.37mm
Card installation method PUSH PUSH Self-eject type
Locating Pin Yes
Foolproof Foolproof
Anti-Buckling Anti-collapse
Hot Swap Support/Normally open
Temperature resistance 260℃
Package SMD
Packaging Method Tape and Reel

Mechanical Properties

Durability 5,000Cycle

Electrical Characteristics

Withstand Voltage 500V AC
Insulation Resistance 1000MΩ Min
Contact Resistance 100mΩ Max
Rated Current 0.5A
Rated Voltage 50V
Declaration:About Product Specifications、Parameter、Life、Operating Temperature、Waterproof Rating and Other Data，Only Represents XunPuInternal Test Results，For Detailed Test Methods，Please Contact XunPuSales Representative。

Product Part Number List

Product Image Part Number Product Description Product Documentation Production Status Delivery Cycle Product Gross Weight MPQ MOQ Remarks Actions
SMN-303A-ARP7 SMN-303A-ARP7 NANO SIM PUSH PUSH 1.37

View Drawings

 		In Production 3~7Day 0.71Gram(g) 1500/plate No Restriction column-free Contact Customer Service
SMN-303A-ACP7 SMN-303A-ACP7 NANO SIM PUSH PUSH 1.37

View Drawings

3DDownload

 		In Production 3~7Day 0.71Gram(g) 1500/Disc No Restriction Catch Contact Customer Service
