TYPEC-307DSW

REACH RoHS ELV

Product Type 16PIN(With 2.0Data version)

Connector Type Female Connector

Product Form Horizontal

Installation Method SMD Type

Waterproof Rating Non-waterproof

Rated Current 5A

Mating Cycles 10,000Cycles

Basic Parameters

Product Type Type-C Female Connector

PINNumber 16PIN

Number of Rows Single Row

Core color Black

Product Form Horizontal SMD

Height Above Board 3.21mm

Angle 90°

Temperature resistance 260℃

Package SMD

Packaging Method Tape and Reel

Mechanical Properties

Durability 10,000Cycles

Withdrawal force 8-20N

Insertion force 5-20N

Electrical Characteristics

Withstand Voltage 100V AC

Insulation Resistance 100mΩ Min

Contact Resistance 40mΩ Max

Rated Current 5A Max

Rated Voltage 20V Max

Declaration:About Product Specifications、Parameter、Life、Operating Temperature、Waterproof Rating and Other Data，Only Represents XunPuInternal Test Results，For Detailed Test Methods，Please Contact XunPuSales Representative。

Product Part Number List

Product Image	Part Number	Product Description	Product Documentation	Production Status	Delivery Cycle	Product Gross Weight	MPQ	MOQ	Remarks	Actions
	TYPEC-307DSW-ACP16		View Drawings 3DDownload	In Production	3~7Day	1.06Gram(g)	800/Disc	No Restriction		Contact Customer Service
	TYPEC-307DSW-ECP16		View Drawings 3DDownload	In Production	3~7Day	1.06Gram(g)	800/Disc	No Restriction		Contact Customer Service
