USB-240

REACH RoHS ELV

Connector Type Female Connector

Product Form Horizontal

Installation Method Plug-in type

Waterproof Rating Non-waterproof

Product Type USB2.0

Basic Parameters

Product Type AFemale-type connector

PINNumber 4pin

Number of Rows Single Row

Number of Rows Horizontal SMD

Interface shape Curled edge/No edge curl

Core color Black

Angle 180°

Temperature resistance 260℃

Package SMD

Packaging Method Blister tray packaging

Mechanical Properties

Durability 1500cycles

Withdrawal force 1.02kgf（MIN）

Insertion force 3.57kgf（MAX）

Electrical Characteristics

Withstand Voltage 500V AC

Insulation Resistance 50mΩ Min

Contact Resistance 30mΩ Max

Rated Current 1.5A

Rated Voltage 30V DC

Declaration:About Product Specifications、Parameter、Life、Operating Temperature、Waterproof Rating and Other Data，Only Represents XunPuInternal Test Results，For Detailed Test Methods，Please Contact XunPuSales Representative。

Product Part Number List

Product Image	Part Number	Product Description	Product Documentation	Production Status	Delivery Cycle	Product Gross Weight	MPQ	MOQ	Remarks	Actions
	USB-240-BRY		View Drawings	In Production	3~7Day	1.32Gram(g)	100/tray	No Restriction		Contact Customer Service
	USB-240-BRW		View Drawings	In Production	3~7Day	1.27Gram(g)	100/tray	No Restriction		Contact Customer Service
