DC-022B

DC-022B
DC-022B

DC-022B

REACH RoHS ELV
Product Form Vertical
Installation Method Plug-in type

Basic Parameters

Product Type DCPower socket
socket inner core 1.3/2.0/2.5
socket outer hole 5.7
Product Form Vertical insertion
Temperature resistance 260℃
Package DIP
Packaging Method bagged

Mechanical Properties

Durability 5,000Cycles

Electrical Characteristics

Withstand Voltage 500V AC
Insulation Resistance 100MΩ Min
Contact Resistance 30mΩ Max
Rated Current 5A
Rated Voltage 30V DC
Declaration:About Product Specifications、Parameter、Life、Operating Temperature、Waterproof Rating and Other Data，Only Represents XunPuInternal Test Results，For Detailed Test Methods，Please Contact XunPuSales Representative。

Product Part Number List

Product Image Part Number Product Description Product Documentation Production Status Delivery Cycle Product Gross Weight MPQ MOQ Remarks Actions
DC-022B-A130 DC-022B-A130

View Drawings

3DDownload

 		In Production 5-8Day 500/bag No Restriction Contact Customer Service
DC-022B-A200 DC-022B-A200

View Drawings

3DDownload

 		In Production 3-5Day 1.634Gram(g) 500/bag No Restriction Contact Customer Service
DC-022B-A250 DC-022B-A250

View Drawings

3DDownload

 		In Production 3-5Day 500/bag No Restriction Contact Customer Service
