RJ45-202

REACH RoHS ELV

Product Type RJ45

Product Form Recessed board

Whether with light No light

Basic Parameters

Product Type RJ45

Product Form Recessed board/Horizontal/Vertical

Locating Pin Yes/None

Whether with light Yes/None

Temperature resistance 260℃

Package SMD/DIP

Packaging Method Blister box packaging

Mechanical Properties

Durability 750 Cycles

Withdrawal force 22N MAX

Insertion force 22N MAX

Electrical Characteristics

Withstand Voltage 500V AC

Insulation Resistance 100mΩ Min

Contact Resistance 40mΩ Min

Rated Current 1.5A

Rated Voltage 125V DC

Declaration:About Product Specifications、Parameter、Life、Operating Temperature、Waterproof Rating and Other Data，Only Represents XunPuInternal Test Results，For Detailed Test Methods，Please Contact XunPuSales Representative。

Product Part Number List

Part Number	Product Documentation	Production Status	Delivery Cycle	MPQ	MOQ	Actions
RJ45-202-007-24	View Drawings 3DDownload	In Production	3~7Day	100/plate	No Restriction	Contact Customer Service
RJ45-202-005-12	View Drawings	In Production	3~7Day		No Restriction	Contact Customer Service
RJ45-202-021-12	View Drawings 3DDownload	In Production	3-7Day	100/Tray	No Restriction	Contact Customer Service
RJ45-202-007-02	View Drawings	In Production	3-7Day	100/Tray	No Restriction	Contact Customer Service
RJ45-202-005-01	View Drawings 3DDownload	In Production	3-7Day	100/Tray	No Restriction	Contact Customer Service
