PH1.27-04-NPWD

PH1.27-04-NPWD

PH1.27-04-NPWD

REACH RoHS ELV
Product Type 1 Pin Header
Product Spacing 1.27mm
Installation Method SMD Type
Single/Double Row Single Row

Basic Parameters

Product Type Pin Header
Pitch 1.27mm
Installation Method SMD
Number of Rows Single Row

Mechanical Properties

Electrical Characteristics

Rated Current 1.0A mps
Withstand Voltage AC 500V
Insulation Resistance 1000MΩ Min
Contact Resistance 20MΩ Max
Operating Temperature -40°C to +105°c
Standard Material PA6T
Declaration:About Product Specifications、Parameter、Life、Operating Temperature、Waterproof Rating and Other Data，Only Represents XunPuInternal Test Results，For Detailed Test Methods，Please Contact XunPuSales Representative。

Product Part Number List

Product Image Part Number Product Description Product Documentation Production Status Delivery Cycle Product Gross Weight MPQ MOQ Remarks Actions
PH1.27-04-05PWD PH1.27-04-05PWD

View Drawings

3DDownload

 		In Production 15-25Day No Restriction Contact Customer Service
PH1.27-04-04PWD PH1.27-04-04PWD

View Drawings

3DDownload

 		In Production 15-25Day No Restriction Contact Customer Service
PH1.27-04-03PWD PH1.27-04-03PWD

View Drawings

3DDownload

 		In Production 15-25Day No Restriction Contact Customer Service
PH1.27-04-02PWD PH1.27-04-02PWD

View Drawings

3DDownload

 		In Production 15-25Day No Restriction Contact Customer Service
PH1.27-04-01PWD PH1.27-04-01PWD

View Drawings

3DDownload

 		In Production 15-25Day No Restriction Contact Customer Service
